We understand how important it is to choose the correct ladder for an application

To help make that task easier we have summarised key loft ladder technical data for our product range and offer a library of technical drawings (in .dwg and .pdf formats).

Also available are a selection of loft ladder installation and operation instructions.

Furthermore, architects, designers, engineers and industry professionals can download NBS product specifications and BIM objects from NBS Source and download Supreme, Elite and Designo loft ladder objects from Bimstore

upreme heavy duty aluminium retractable electric loft ladder with insulated trapdoor

Loft ladder technical data, BIM objects and NBS Source product specifications…

Quality:

The Supreme, Designo, Mini, Elite, Piccolo, Cadet and ProfiLine are manufactured to EN 14975 (DN 4570).

(Please note that where 250 mm wide treads are required in the Supreme and Elite models, these do not comply with EN 14975 (DN 4570))

Insulation:

Wooden Loft Ladders

  Type Operation U-value (heat transfer coefficient) W/m2K Class 4 air permeability certified
Designo & Designo Passivhaus 3-part folding Manual 0.60 Yes
Designo DD 3-part folding Manual 0.29 Yes
Cadet 3 3-part folding Manual 0.90 Yes
Quadro & Quadro 2 3-part folding & 2-part sliding Manual 0.77 Yes
Quadro DD 3-part folding Manual 0.46 Yes
ProfiLine F30/F30 Plus/F60 3-part folding Manual 0.92 Yes

Aluminium Loft Ladders

  Type Operation U-value (heat transfer coefficient) W/m2K Class 4 air permeability certified
Supreme Concertina/ Retractable Manual or Electric 0.58 Yes
Supreme DD Concertina/ Retractable Manual or Electric 0.29 Yes
Supreme F30 Concertina/ Retractable Manual or Electric 0.80 Yes
Supreme F30/F60 Steel Concertina/ Retractable Manual or Electric 0.57 No
Supreme F90 Steel Concertina/ Retractable Manual or Electric 0.93 No
Supreme Vertical Concertina/ Retractable Manual 0.58 No
Ecco Concertina/ Retractable Manual 0.77 Yes
MiniLine F30/F30 Plus/F60 Concertina/ Retractable Manual 0.92 Yes

Weather Resistant Flat Roof Hatch (‘Supreme’ product family)

  • Roof hatch = U-value 0.68 W/m2K
  • Trapdoor = U-value 0.58 W/m2K
  • Combined = U-value 0.37 W/m2K
  • Weatherproof roof hatch/flat roof exit with wooden hatch box and trapdoor F30 – Combined = U-value 0.43 W/m2K
  • Weatherproof roof hatch/flat roof exit with steel hatch box and trapdoor F30/F60 – combined = U-value 0.24 W/m2K
  • Weatherproof roof hatch/flat roof exit with wooden hatch box and trapdoor F90 – combined = U-value 0.29 W/m2K
Fire Resistance:

Fire Testing and Certification

F30, F30 Plus, F60 fire rated loft ladders with wooden hatches have been tested to DIN 4102 Part 2 by MPA Braunschweig. Copies of the certificates are available upon request. Certifications are based upon testing from below, with the exception of F30 Plus, which is certified for 30 minutes from below and above.

F30, F60 and F90 fire rated loft ladders with steel hatches have been tested (from below) to DIN 4102 Part 2 by IBS Linz. Testing was completed in April 2021 and copies of the certs are expected to be available in June/July 2021. The maximum aperture dimension that could be tested was 1400 mm x 800 mm. We understand that the fire certification will have an allowance that covers larger apertures, but until the certs are available we recommend customers specify and order hatches up to 1400 mm x 800 mm.

EI230, EI260, EI290 and EI2120 fire resistant loft ladders are tested to tested according to ÖNORM 3860, EN 1634-1, EN1363-1. Copies of the certificates are available upon request.

Supreme F30, F60 and F90 steel hatch box construction:

1.5 mm thick steel hatch box with a steel trapdoor. The trapdoor is made from 2 layers of 1.5 mm thick sheet steel infilled with 38 mm of mineral wool to give a 30 minute fire resistance or 75 mm of mineral wool to give a 90 minute fire resistance. There is a 40 mm wide lip to the bottom of the lining around the external edge, which is designed to butt up against the ceiling to help prevent flame and smoke ingress. Similarly, there is also a lip to the bottom of the steel trapdoor, which extends to within 15 mm of the lip on the lining.

For use in fire retardant wooden and reinforced concrete ceilings.

Supreme F30 wooden hatch box construction:

Wooden hatch box and trapdoor are made from fire-resistant B1 chipboard. Suitable for use in fire retardant wooden and concrete ceilings.

MiniLine F30, F30 Plus and F60 wooden hatch box construction:

Wooden hatch box and trapdoor are made from fire-resistant B1 chipboard. The MiniLine F30 and F60 fire rated loft hatch and ladders are suitable for use in fire retardant wooden beams and concrete ceilings. MiniLine F30 Plus fire rated loft hatch and ladder is only suitable for use in fire retardant concrete ceilings.

ProfiLine F30, F30 Plus and F60 wooden hatch box construction:

Wooden hatch box and trapdoor are made from fire-resistant B1 chipboard. The ProfiLine F30 and F60 fire rated loft hatch and ladders are suitable for use in fire retardant wooden beams and concrete ceilings. ProfiLine F30 Plus fire rated loft hatch and ladder is only suitable for use in fire retardant concrete ceilings.

Important – Please ensure that you maintain the fire resistance by filling the gap between the fire rated hatch box and the structural opening with a fire resistant mortar to a depth of at least 200 mm. We recommend mortar class 3 according German standard DIN 18580.

Materials:

The Elite ladder and the ladder within the Supreme model are manufactured from die-cast aluminium alloy.

The Piccolo ladder and the ladder within the Mini are manufactured from extruded aluminium alloy.

Load Bearing:

Supreme – 200 kg per tread – overall unit 500 kg/m2

Elite / Elite Vertical – 200 kg per tread – overall unit 500 kg/m2

Ecco – 150 kg per tread – overall unit 350 kg/m2

Piccolo / Piccolo Premium / Piccolo Premium Vertical – 150 kg – per tread – overall unit 350 kg/m2

Designo / Designo DD – 180 kg per tread – overall unit 420 kg/m2

Cadet 3 – 150 kg per tread – overall unit 350 kg/m2

Quadro – 150 kg per tread – overall unit 350 kg/m2

ProfiLine – 150 kg per tread – overall unit 350 kg/m2

Klimatec 160 – 250 kg per tread

Isotec / Isotec Luxe /Isotec 200 – 250 kg per tread

Tread Rise:

Concertina / retractable ladder tread rise is variable and subject to the exact floor to ceiling height – typical tread rise will be between 277mm to 280mm.

Construction of hatch box and trapdoor:

Supreme – hatch box and trapdoor both 18mm thick laminated wood.

Supreme F30 with a wooden hatch box and trapdoor – hatch box is made from 19 mm chipboard and coated with Pyroex. The trapdoor is made from 28mm chipboard and coated with Pyroex.

Elite – backboard is made from 18mm blockwood

Mini – hatch box and trapdoor both 18mm thick laminated wood.

Designo & Designo Passivhaus – hatch box made from 18mm thick laminated wood, with 67mm thick insulated trapdoor.

Designo DD – hatch box made from 18mm thick laminated wood. 67mm thick insulated lower trapdoor and 66mm thick insulated top cover.

Quadro – hatch box made from 18mm thick laminated wood.

Cadet

ProfiLine

Esca 11

Hatch box Minimum depths:

Supreme with wooden hatch box – 200mm

Supreme F30 with steel hatch box – 240mm

Supreme F60 / F90 with steel hatch box – 240mm

Supreme F30 with wooden hatch box and trapdoor – 240mm

Ecco – 200mm

MiniLine – 220mm

Designo – 185mm

Design DD – 670mm

Quadro – 185mm

Cadet 3 – 190mm

ProfiLine – 220mm

When installing a deep hatch box within a void e.g. an area between a suspended ceiling and the main ceiling, then we would recommend the use of bracing from the main ceiling to the outside of the hatch box to add stability.

Minimum lengths for electrical operation:

(Lengths below are applicable for a floor to ceiling height of up to 2500mm high and will increase with greater heights)

Supreme Electric – Wooden hatch box and trapdoor (with insulation) – 1100 mm

Supreme F30 Steel Electric – Steel hatch box and trapdoor F30 rated – 1150 mm

Supreme F6/F90 Steel Electric – Steel hatch box and trapdoor F60 or F90 rated – 1150 mm



BIM Components

Premier Loft Ladders BIM objects are available to download from the NBS Source BIM library. Furthermore, they are available in both IFC and Revit format. Please follow the link below to explore the BIM objects available for download.

Premier Loft Ladders BIM objects are available from the NBS National BIM Library

NBS Source

To help designers specify our products in just one click, a selection of technical specifications for our most popular products can be found on NBS Source. Please click on the links or images below to be taken to the specification…

NBS Source Partner. Premier Loft Ladders products can be found on NBS Plus

CAD drawings and installation/operation manuals…

Supreme Loft Ladder

Supreme loft ladder with a wooden hatch box and insulated trapdoor – 6000221D

Supreme loft ladder with a wooden hatch box – Additional tread schemes

Supreme fire rated loft ladder with F30 wooden hatch box and trapdoor – 6000225C

Supreme fire rated loft ladder with F30 steel hatch box and trapdoor – 6000227F

Supreme fire rated loft ladder with an F60 / F90 steel hatch box and trapdoor – 6000288F

Supreme loft ladder with a wooden hatch box and trapdoor plus weatherproof roof hatch plus 1 additional treads – 6000211E

Supreme loft ladder with a wooden hatch box and trapdoor plus weatherproof roof hatch plus 2 additional treads – 6000212E

Supreme loft ladder with a wooden hatch box and trapdoor plus weatherproof roof hatch plus 3 additional treads – 6000213E

Supreme fire rated loft ladder with a wooden hatch box and trapdoor F30 plus weatherproof roof hatch – 6000214D

Supreme fire rated loft ladder with F30 steel hatch box and trapdoor plus weatherproof roof hatch – 6000215C

Supreme fire rated loft ladder with F60 / F90 steel hatch box and trapdoor plus weatherproof roof hatch – 6000286C

Supreme Vertical Loft Ladder

Supreme Vertical loft ladder with wooden hatch box and insulated trapdoor – 6000238C

Supreme Electric Loft Ladder

Supreme electric loft ladder with wooden hatch box and insulated trapdoor – 6000455B.

Elite Loft Ladder

Elite loft ladder drawing – 6000231E

Elite 9 tread loft ladder for installation in conventional ceiling openings

Elite 9 tread loft ladder for installation in deep hatches or on vertical walls

Elite 10 tread loft ladder for installation in conventional ceiling openings

Elite 10 tread loft ladder for installation in deep hatches or on vertical walls

Elite 11 tread loft ladder for installation in conventional ceiling openings

Elite 11 tread loft ladder for installation in deep hatches or on vertical walls

Elite 12 tread loft ladder for installation in conventional ceiling openings

Elite 12 tread loft ladder for installation in deep hatches or on vertical walls

Elite loft ladder with high-backboard – 6000419C

Elite loft ladder with high-backboard – backboard heights

Elite Vertical loft ladder (for mezzanine floors and vertical wall openings) – 6000453C

MiniLine F30 / F30 Plus / F60

MiniLine Fire Resistant loft ladder – 6000495B

ProfiLine F30 / F30 Plus / F60

ProfiLine  F30, F30 Plus, F60 loft ladder drawing – 6000463

Ecco Loft Ladder

Ecco concertina loft ladder – 6000493

Ecco concertina loft ladder with flat roof access hatch – 6000494B

Klimatec 160 Passivhaus Loft Ladder

Klimatec 160 Passivhaus loft ladder – 7000303

Isotec EI230 / EI260 / EI290 / EI2120

Isotec Fire rated loft ladder – 7000301A

Isotec 200 EI260

Isotec 200 Fire rated loft ladder – 7000302A

Piccolo and Piccolo Premium Loft Ladder

Picciolo and Piccolo Premium loft ladder – 6000416B

Piccolo Premium Vertical loft ladder – 6000417

Designo Loft Ladder & Loft Hatch

Designo and Designo Passivhaus Loft Ladder – 6000392B

Designo Loft Hatch – 6000499

Quadro Loft Ladder

Quadro 3 part wooden – 6000426C

Loft Ladder Installation Manuals

Supreme Installation Instructions – INST 001-2017

Elite Installation Instructions – INST 003-2017

Elite with high backboard Installation Instructions – INST 004-2017

Elite Vertical Installation Instructions – INST 005-2017

Piccolo & Piccolo Premium Installation Instructions – INST 006-2017

Piccolo Premium Vertical Installation Instructions – INST 007-2017

Installation manuals for other loft ladders and accessories are available upon request.  Please contact us.

Technical Data Sheets…

Loft Ladder Technical Data Sheets

Supreme – DS-SUP

Supreme Electric – DS-SUP-ELEC

Supreme with F30 Steel Hatch – DS-SUP-F30-ST

Elite – DS-ELI

Ecco – DS-ECCO

Designo – DS-DES

Designo Passive House – DS-DES-PH

Quadro – DS-QUAD

Cadet 3 – DS-CAD

ProfiLine – DS-PRO

Klimatec 160 – DS-KLI

Isotec – DS-ISO

Isotec 200 – DS-ISO-200

LWT – DS-LWT

LWT Passive House – DS-LWT-PH
