Wooden loft ladder and hatch box Load rating of 180kg per tread Overall Load rating. 420kg/m2 Supplied with handrail as standard Available made-to-measure Thermally insulated. U value = 0.60W/m2K Class 4 certified airtight seal

Designo Loft Ladder

Highly Insulated wooden loft ladder…

…sets the standard for long-lasting quality and design

From £715 (excl. VAT)

Including delivery to any UK mainland address

Available from stock for delivery in 1-2 days

BUY NOW

KEY FEATURES

Material: Wood
Operation: 3-part folding
Load capacity: 180 kg per step
U-value: 0.60 W/m²K
Max floor-to-ceiling height: 3.3 m

FIND OUT MORE

Designo wooden loft ladder with insulated hatch. Premier Loft Ladders

Designo with 6 point locking mechanism for air tight seal

WDL sealing and insulation tape for an airtight connection between the loft ladder hatch box and the building

Designo heavy duty wooden loft ladder with ant-sip treads. Premier Loft Ladders

Designo insulated hatch in close position

Designo non-slip protective feet. From Premier Loft Ladders

Spring counter balance makes opening and closing the wooden loft ladder easier

Designo insulated loft hatch and ladder with 6-point locking mechanism for air tight seal

Designo high strength heavy duty wooden loft ladder. Premier Loft Ladders

Designo wooden loft ladder with insulated hatch

The Designo wooden loft ladder perfectly balances aesthetics with strength and quality. Also, it is quiet, smooth and easy to operate. The 3-part folding heavy duty wooden loft ladder is contained within, and attached to, an insulated wooden hatch box. It offers excellent energy efficiency thanks to a highly insulated trapdoor with 6-point locking mechanism providing an airtight seal.

The Designo is also fitted with the patented WDL sealing and insulation tape, which provides a perfect seal between the hatch box and building and saves time during installation. Made of tear-resistant material, it also offers thermal and acoustic insulation.

Can be ordered as a Passive House Institute certified component – see Designo Passive House

Key benefits at a glance

Traditional wooden loft ladder design.
High strength ladder.
Load capacity of 180 kg per step.
High energy efficiency of 0.60 W/m²K.
6-point locking trapdoor for an airtight seal when closed (Class 4).
WDL insulation and sealing tape for airtight seal with the building.
Wide steps with anti-slip profile for comfort and safety.
Available in standard sizes or made-to-measure with a range of options and accessories.

3-part folding wooden loft ladder with adjustable tilt

Traditional wooden loft ladder design
- Attractive styling
- Strength
- Quality

High strength, heavy duty loft ladder, with a load capacity of 180 kg per step

Supplied assembled in a hatch box with insulated trapdoor
- Trapdoor supplied with a white finish to both sides
- Standard hatch box height of 200 mm, but can be specified for heights between 185 mm to 710 mm
- 6-point locking mechanism
- Pre-drilled holes in hatch box for quick and easy installation

High energy efficiency (U-value of 0.60 W/m²K, calculated by manufacturer according to DIN EN ISO 6946)
- Reducing loss of heat and lowering energy costs
Class 4 air permeability certified (tested to DIN EN 12207 / 12114 by IFT Rosenheim)

Available in standard hatch sizes for floor-to-ceiling heights between 2300 mm and 2800 mm

Can be made-to-measure to meet your exact dimensional requirements, for floor-to-ceiling heights of up to 3300 mm (contact us for details)

Wide steps / treads with anti-slip profile for comfort and safety
- Step width of 330 mm
- Step depth of 80 mm

Supplied ready to install with a range of accessories
- Handrail for safety
- Protective feet
- Operating pole with square shaft
- Snap-on cover strips in white

Available certified by the Passive House Institute (Passivhaus Institut) as a passive house component. Visit the Designo Passive House product page for further details.

Can be ordered with a secondary upper hatch for applications requiring particularly high levels of thermal insulation (U value of 0.29 W/m²K). Visit the Designo DD product page for more information.

The Designo loft ladder is available in the following standard sizes that can be ordered on line.

Clear room height (mm)	Opening length x width (mm)	Case height (mm) *
2300 – 2800	1200 x 600	200
2300 – 2800	1200 x 700	200
2300 – 2800	1300 x 700	200
2300 – 2800	1400 x 700	200

Available made-to-measure…

The Designo loft ladder can also be ordered made-to-measure for floor-to-ceiling heights from 2.3 m to 3.3 m, and opening sizes from 1200 mm long x 550 mm wide.

Please download a ‘customer specification sheet’ (below) and contact us to discuss your requirements and to arrange a quotation.

CSS PLL Designo

Manufactured and tested to EN 14975 (certified by TÜV SÜD)

Supplied with a manufacturer’s 2-year full warranty and 10-year parts warranty

The Designo loft ladder is available as a BIM model/object from the NBS National BIM library in IFC and Revit format…

Alternatively, please click here to view our full range of available BIM models.

Video

Accessories

The following accessories are only available for order with a loft ladder. Please make sure to add the required accessories to your cart before checkout, or contact us directly to discuss your requirements.
