BD90 fire rated wooden loft ladder. 90 mins protection from above and below

Wooden loft ladder and hatch box Load rating of 150kg per tread Overall Load rating. 260kg/m2 Supplied with handrail as standard Available made-to-measure Thermally insulated. U value = 0.69W/m2K F90 Fire rated loft ladder. 90 minutes from above and below.

BD90 F90 Fire Rated Wooden Loft Ladder

90 minute fire protection from above & below…

…combining traditional styling and fire resistance

£975 (excl. VAT)

CONTACT US FOR A QUOTE

KEY FEATURES

Material: Wood
Operation: 3-part folding
Fire resistance: F90 Plus
Load capacity: 150kg per step
U-value: 0.69 W/m2K
Max floor-to-ceiling height: 3.36m

FIND OUT MORE
BD90_Full_open_512x512
BD90_Hatch box_open_512x512

The BD90 fire rated wooden loft ladder certified to DIN EN 4102-2 for 90 minutes from below and above (F90 Plus). It is available made-to-measure. Furthermore, the BD90 is supplied as a ready to fit unit, consisting of a 3-part folding wooden ladder contained within a wooden hatch box and an insulated trapdoor.



Key benefits at a glance

  • Traditional wooden loft ladder design.
  • Load capacity of 150kg per step.
  • Good energy efficiency of 0.69 W/m2K.
  • Wide steps with anti-slip profile for comfort and safety.
  • Hatch trap door finished in white on both sides.
  • Certified fire resistant to F90 Plus.
  • Available made-to-measure.



  • 3 part folding wooden loft ladder with adjustable tilt
  • Traditional wooden loft ladder design
  • Load capacity of 150kg per step
  • Supplied assembled in a hatch box with insulated trapdoor
    • Trapdoor supplied with a white finish to both sides
    • Hatch box height of 190mm
  • Fire resistant hatch box – certified to DIN EN 4102-2 for 90 minutes from below and above (F90 Plus).
  • Energy efficient (U-value of 0.69 W/m2K, calculated as building component)
    • Reducing loss of heat and lowering energy cost
  • Made-to-order to meet your exact dimensional requirements, for floor-to-ceiling heights of up to 3360mm (contact us for details)
  • Wide steps / treads with anti-slip profile for comfort and safety
    • Step width of 400mm
    • Step depth of 83mm
  • Supplied ready to install with a standard with a range of accessories
    • Protective feet
    • Painted white architrave

N/A

Available made-to-measure…

The BD90 fire rated loft wooden ladder is available made-to-measure for floor-to-ceiling heights from 2.54m to 3.36m, and opening sizes from 1200mm to 1500mm long x 600mm to 814mm wide.

Please contact us to discuss your requirements and to arrange a quotation.

  • Manufactured to EN 14975
  • DIN 4102-2 certified for fire resistance of 90 minutes from below and above (F90 Plus)
